Master Excel VBA Web Scraping for Data Extraction

Diving Into Web Scraping with Excel VBA

Web scraping is essentially about grabbing data from websites. You pull the HTML structure of a page and then sift through it to extract the bits of information you need. While Python often takes the spotlight for this kind of task, it's far from the only player in the game.

Enter Visual Basic for Applications (VBA). This is the scripting language built into Microsoft Office applications, and it's particularly handy within Excel. VBA lets you automate all sorts of repetitive actions and push the results directly into your spreadsheets.

Since Excel is already a powerhouse for handling numbers and organizing data, pairing it with VBA creates a surprisingly effective web scraping tool. A big plus? You skip the hassle of managing separate files and formatting – VBA can place the scraped data right where you want it in your Excel sheet.

Setting Up Your Excel for VBA Scraping

By default, the VBA capabilities in Excel are tucked away. You'll need to enable them first. Here’s how to uncover the Developer tools:

1. Open Microsoft Excel. Go to the File menu, usually found in the top-left corner.

2. Look towards the bottom of the menu that appears and click on Options.

3. In the Excel Options window, find and select Customize Ribbon from the list on the left.

4. On the right side of this window, under 'Main Tabs', you'll see a list of available tabs. Scroll through it until you find Developer. Tick the checkbox next to it.

5. Click OK to close the Options window.

You should now see a new 'Developer' tab appear in the main Excel ribbon at the top. This tab is your gateway to building our VBA web scraper.

Click on the 'Developer' tab, and on the far left, you'll spot a button labeled Visual Basic. Clicking this opens the VBA editor – a separate window where the coding happens. This is your integrated development environment (IDE) for VBA.

Before we start coding, we need to tell VBA which tools (or 'references') we'll need. Think of these like libraries or modules in other programming languages.

In the VBA editor window:

1. Go to the Tools menu and select References....

2. A dialog box will pop up with a long list of available references. Scroll down (you can press 'M' to jump) and find these two:

   • Microsoft HTML Object Library

   • Microsoft Internet Controls

3. Check the boxes next to both of them.

4. Click OK.

With these references enabled, we're ready to start scripting.

Understanding the Core VBA Scraping Tools

The two references we just added are crucial. The Microsoft HTML Object Library equips VBA with the ability to understand and manipulate HTML documents. It allows your code to parse the structure of a webpage, select specific elements (like titles, paragraphs, or tables), and extract their content.

The Microsoft Internet Controls library, meanwhile, provides programmatic access to Internet Explorer (or more accurately, the underlying MSHTML engine). While IE itself might feel like a relic, this control allows VBA to open web pages, wait for them to load, and interact with them, effectively automating a browser session behind the scenes.

You can't really scrape websites effectively in VBA without these two. One lets you navigate and fetch the pages (Internet Controls), and the other lets you dissect the fetched content (HTML Object Library).

Interestingly, these tools give us two primary methods for fetching web data:

1. Automating the Browser Engine (via Internet Controls): This method simulates browser activity, which is often better for websites that rely heavily on JavaScript to load content dynamically.

2. Direct HTTP Requests (via XMLHTTP): Similar to how libraries like Python's `requests` work (you can read more about Python Requests here), VBA can send requests directly to a web server and receive the raw HTML without rendering the page in a browser. This is generally faster but can sometimes be easier for websites to block.

Crafting Your First VBA Web Scraper

Let's get practical. Go back to your main Excel window. It's a good idea to create a dedicated sheet for your scraped data. Add a new sheet (click the '+' button at the bottom) and perhaps rename it to something like "ScrapedData".

Now, hop back into the VBA editor. In the project explorer pane (usually on the left), find your workbook and the sheet you just created (it might look like 'Sheet1 (ScrapedData)'). Right-click on your workbook's name (like 'VBAProject (YourWorkbookName.xlsm)'), hover over Insert, and choose Module. A blank white pane will appear – this is where you'll write your VBA code.

Let's start with the Internet Explorer automation method. We'll scrape book titles from a practice website.

Sub ExtractBookTitlesIE()
    ' Declare variables
    Dim browser As Object ' To hold the browser instance
    Dim htmlDoc As Object ' To hold the HTML document
    Dim elements As Object ' To hold the collection of found elements
    Dim element As Object ' To loop through individual elements
    Dim targetSheet As Worksheet ' To specify where data goes
    Dim rowNum As Integer ' To track the row for output

    ' Set the target worksheet
    Set targetSheet = ThisWorkbook.Sheets("ScrapedData") ' Change "ScrapedData" if you used a different name
    targetSheet.Cells.ClearContents ' Clear previous data
    targetSheet.Cells(1, 1).Value = "Book Title" ' Add a header
    rowNum = 2 ' Start outputting data from row 2

    ' Create an Internet Explorer instance
    Set browser = CreateObject("InternetExplorer.Application")
    browser.Visible = False ' Keep the browser hidden

    ' Navigate to the target URL
    browser.navigate "https://books.toscrape.com/"

    ' Wait for the page to load completely
    Do While browser.Busy Or browser.readyState <> 4
        DoEvents ' Yield control to allow processing
    Loop

    ' Get the HTML document from the loaded page
    Set htmlDoc = browser.document

    ' Find elements by CSS class name (book titles are in h3 > a)
    ' Let's target the 'a' tags directly inside 'h3' within product pods
    Set elements = htmlDoc.querySelectorAll(".product_pod h3 a") ' Using querySelectorAll for CSS selector

    ' Check if any elements were found
    If elements.Length > 0 Then
        ' Loop through each found element
        For Each element In elements
            ' Extract the title (stored in the 'title' attribute of the 'a' tag)
            targetSheet.Cells(rowNum, 1).Value = element.getAttribute("title")
            rowNum = rowNum + 1 ' Move to the next row
        Next element
    Else
        targetSheet.Cells(2, 1).Value = "No book titles found."
    End If

    ' Clean up: Close IE and release objects
    browser.Quit
    Set browser = Nothing
    Set htmlDoc = Nothing
    Set elements = Nothing
    Set element = Nothing
    Set targetSheet = Nothing

    MsgBox "Scraping finished!"
End Sub

Here's a breakdown of what that script does:

• It sets up variables for the browser, HTML content, target elements, and the Excel sheet.

• It creates an invisible Internet Explorer instance.

• It navigates to `https://books.toscrape.com/` and patiently waits for the page to finish loading.

• It grabs the page's HTML source code.

• It uses `querySelectorAll` (a powerful way to select elements using CSS selectors) to find all the links (`a` tags) that are inside `h3` tags within elements having the class `product_pod`. These links contain the book titles in their `title` attribute.

• It checks if any titles were found. If yes, it loops through them, extracting the value of the `title` attribute for each and writing it to the "ScrapedData" worksheet, moving down one row each time.

• Finally, it closes the browser instance and tidies up the variables.

To run this, make sure the code is in the module window in the VBA editor, then press the 'Run' button (looks like a play icon) or press F5.

Using Direct HTTP Requests (XMLHTTP)

Now, let's try the faster, more direct approach using `MSXML2.ServerXMLHTTP`. This avoids loading a full browser engine.

Sub ExtractBookTitlesXMLHTTP()
    ' Declare variables
    Dim httpReq As Object       ' For the HTTP request
    Dim htmlDoc As Object       ' To parse the HTML response
    Dim elements As Object      ' To hold found elements
    Dim element As Object       ' To loop through elements
    Dim targetSheet As Worksheet ' Target sheet
    Dim rowNum As Integer       ' Output row tracker

    ' Set the target worksheet
    Set targetSheet = ThisWorkbook.Sheets("ScrapedData") ' Adjust name if needed
    targetSheet.Cells.ClearContents                   ' Clear old data
    targetSheet.Cells(1, 1).Value = "Book Title"      ' Header
    rowNum = 2                                        ' Start data output below header

    ' Create the ServerXMLHTTP object
    Set httpReq = CreateObject("MSXML2.ServerXMLHTTP.6.0")

    ' Send a GET request to the URL
    httpReq.Open "GET", "https://books.toscrape.com/", False ' False makes it synchronous
    httpReq.send

    ' Check if the request was successful (HTTP status code 200)
    If httpReq.Status = 200 Then
        ' Create an HTMLFile object to parse the response text
        Set htmlDoc = CreateObject("HTMLFile")
        htmlDoc.body.innerHTML = httpReq.responseText ' Load the HTML into the parser

        ' Find elements (same logic as before)
        Set elements = htmlDoc.querySelectorAll(".product_pod h3 a")

        ' Check if elements were found
        If elements.Length > 0 Then
            For Each element In elements
                ' Extract the title attribute
                targetSheet.Cells(rowNum, 1).Value = element.getAttribute("title")
                rowNum = rowNum + 1 ' Next row
            Next element
        Else
            targetSheet.Cells(2, 1).Value = "No book titles found via XMLHTTP."
        End If
    Else
        ' Request failed, show an error message
        MsgBox "Failed to retrieve the page. Status: " & httpReq.Status & " " & httpReq.statusText
    End If

    ' Clean up objects
    Set httpReq = Nothing
    Set htmlDoc = Nothing
    Set elements = Nothing
    Set element = Nothing
    Set targetSheet = Nothing

    MsgBox "XMLHTTP Scraping finished!"
End Sub

Much of this code is similar to the IE version, especially the part that parses the HTML and extracts the data. The main difference lies in how the web content is fetched. Instead of controlling a browser, we create an `MSXML2.ServerXMLHTTP` object, send a direct `GET` request, and check the HTTP status code (`200` means success). If successful, we load the `responseText` (the raw HTML) into an `HTMLFile` object for parsing.

This method is often quicker, but be aware: some websites have security measures that can more easily detect and block direct requests compared to requests coming from a simulated browser.

Going Further with VBA Web Scraping

VBA's capabilities don't stop with the built-in tools. You can enhance your scraping projects significantly.

For instance, while `Internet Controls` uses the IE engine, you might want to automate more modern browsers like Chrome or Firefox. This is possible by integrating Selenium with VBA. You'll need to install SeleniumBasic (a VBA wrapper for Selenium WebDriver) and the corresponding WebDriver executable for your chosen browser. This setup allows for more robust automation of contemporary browsers.

Websites often load content dynamically using JavaScript after the initial page load. The `Do While browser.Busy Or browser.readyState <> 4` loop combined with `DoEvents` helps wait for the initial load. For content that loads later (e.g., infinite scroll or clicking 'load more'), you might need to add explicit waits or trigger the necessary interactions (like simulating clicks) within your VBA code before attempting to scrape the newly loaded data.

Data parsing is also built right into VBA's toolkit. We used `querySelectorAll` in our examples, but the `Microsoft HTML Object Library` also offers functions like `getElementsByTagName`, `getElementById`, and `getElementsByClassName` to navigate the HTML Document Object Model (DOM) and pinpoint the exact data you need. Properties like `innerText` (just the text) or `outerText` (text plus surrounding HTML tags) give you flexibility in how you extract content from the selected elements.

One common challenge, especially when using the faster XMLHTTP method or scraping frequently, is encountering IP address blocks. Websites often limit request frequency from a single IP to prevent abuse. This is where proxies become essential. Using a reliable proxy service allows you to route your requests through different IP addresses, making your scraping appear more like organic user traffic. For demanding tasks, high-quality residential proxies, like those offered by Evomi, provide IPs associated with real devices, significantly reducing the chances of getting blocked. Evomi provides ethically sourced proxies with competitive pricing and robust support, based right here in Switzerland.

Wrapping Up

Excel VBA offers a potent combination for web scraping, especially if you're already comfortable within the Microsoft Office environment. It streamlines the process by integrating data extraction, parsing, and analysis directly within Excel spreadsheets. While perhaps not as mainstream as Python for large-scale scraping operations, VBA holds its own for smaller projects, specific automation tasks, or when direct Excel integration is a key requirement.

It leverages built-in Microsoft technologies and can be extended with tools like Selenium. Learning VBA for web scraping adds a unique and practical skill to your data gathering toolkit, although it does mean working with a language less commonly used outside the Office ecosystem.
